YOGOGAWA AQ1000 OTDR
General Parameters
Testing Wavelength 1310/1550nm
Dynamic Range 30/32dB
Event Dead Zone 0.8m
Attenuation Dead Zone 4m
Pulse Width 3ns~20μs
Testing Range Dead zone, 500m, 2km, 5km, 10km, 40km, 80km, 120km, 160km, 240km
Sampling Resolution ≤ 0.05dB/dB
Linearity ≤ 0.05dB/dB
Display Resolution 0.01dB
Loss Threshold Step 0.01dB
Loss Resolution 0.001dB
Distance Resolution 0.01m
Sampling Point Maximum 128,000 points
Distance Accuracy ± (1m+measuring distance×3×10-5+sampling resolution)
Data Storage 40000 groups of curve
Internal Parameter
Laser Launcher Type LD/TT/WU
Output Power 10mW
Distance Range About 12km
Optical Connector FC/UPC OR SC/UPC
Output Wavelength 650nm ± 10nm
Modulation Frequency CW / 2Hz
Physical Parameters
Interface Internet port, 3 USB port
Display 7 inch TFT-LCD Touch Screen
Battery 7.4V/4.4Ah lithium battery, continuous 5.5 hours
Working Temp -10°C~+50°C
Storage Temp -20°C~+75°C
Dimension 253×168×73.5mm / 1.5kg
