Description
Speicifications
Fiber alilgnment 6 motors Core to core alignment
Applicable fibers Single / SMF (G.652/657), MMF (G.651), DSF (G.653), NZDSF (G.655), BI(G.657)
Cladding dia. / Sheath dia. 80-150μm / 100-1000μm
Cleave length 5mm to 16mm with sheath clamp
Splice mode Total 100 modes, supports self-defined mode and parameter
Typical splice time 7 sec. SM FAST
Typical splice loss 0.02dB (SM), 0.01dB (MM), 0.04dB (DSF) ,0.04dB (NZDS) and 0.02dB(BI)
Return loss >>60dB
Heating mode Max. 20
Heating time 9 sec.
Applicable protection sleeve 10~60mm
Splice result storage Last 20,000 splices
Splice image storage Max.800
Viewing methods 2 axis CMOS camera with 4.73” HD color capacitive touchscreen
Magnification Supports X / Y or both X and Y simultaneously, maximum up to 760X magnification
Wireless connectivity GPS positioning and tracking system through inbuilt SIM card
Port MicroSD and USB port for software upgrade / data management
Electrode life Typical 5000 splices
