Description
SPECIFICATIONS
Wavelength: Multimode: 850nm/1300nm
Measuring Range Settings: Min 100m Max 100km
Touch Screen or Hard Key Functions
OTDR data format: SOR format
Onboard Features: Power Meter, Light Source, OTLS, VFL, OTDR, Graphical Event Map Display, Optional Network Cable Test.
Keyboard input, edit or save file name and line number
4.3-inch TFT screen, 800 x 480 pixel display
Units of measurement: Kilometers, Kilofeet, Miles
26dB Dynamic Range at 1300nm
UPC OTDR port with SC & FC interchangeable adapter
USB Connector Inspection Probe (sold separately)
Lithium Batteries Lasts 8 hours or more on full charge
PDF Batch Reporting Software Included
FEATURES
• Wavelength: Single mode:1310/1550nm or Multimode 850nm/1300nm
• Measuring Range Settings: Min 100m – Max 100km
•Touch Screen or Hard Key Functions
• OTDR data format: SOR format
• Onboard Features: Power Meter, Light Source, OLTS, VFL, OTDR,
Graphical Event Map Display, Optional Network Cable Test.
• Keyboard input, edit or save file name and line number
• 4.3-inch TFT screen, 800 x 480 pixel display
• Units of measurement: Kilometers, Kilofeet, Miles
• 26dB Dynamic Range
• APC OTDR port with SC & FC interchangeable adapters
• USB Connector Inspection Probe (sold separately)
• Lithium Batteries – Lasts 8 hours or more on full charge
• PDF Batch Reporting Software Included
